Software Engineering with Objects: The Case Study: Part 2 - L. Barroca

In this unit, we produce a structural model, complete the analysis of the case study and produce the design for the first iteration of the UP approach. It shows that the analysis and design is being driven from the requirements and establishes some basic traceability between requirements and design. The unit begins by producing a diagram in which the classes represent concepts from the domain rather than software. This allows us to represent sets of objects that are of relevance to the problem we are trying to solve.
