Technical drawings of aircraft of World War II - Paul E. Eden

With the aid of 116 extraordinarily detailed and accurate line drawings, Technical Drawings of Aircraft of World War II reveals how a wide selection of classic military aircraft were put together - both inside and out. Showing how aircraft developed during the war, each complex line drawing is annotated with an exhaustive key featuring everything from air ducts to the nosewheel leg pivot mounting. The illustrations are complemented by colour photographs with extended captions, plus detailed information about each aircraft's operational specifications. From the Messerschmitt Bf109k-4 to the North American B-25 Mitchell, Technical Drawings of Aircraft of World War II is an invaluable reference guide for anyone interested in how classic aircraft worked.
